Display | |||
---|---|---|---|
Brightness (ANSI lumens)
3400
|
Brightness (ANSI lumens)
3500
|
Brightness (ANSI lumens)
4000
|
|
Resolution
1080P (1920x1080)
|
Resolution
1080P (1920x1080)
|
Resolution
1080P (1920x1080)
|
|
Native Aspect Ratio
16:9
|
Native Aspect Ratio
16:9
|
Native Aspect Ratio
16:9
|
|
Contrast Ratio (FOFO)
15,000:1
|
Contrast Ratio (FOFO)
10,000:1
|
Contrast Ratio (FOFO)
3,000,000:1
|
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
|
Light Source
Lamp
|
Light Source
Lamp
|
Light Source
Laser
|
|
Light Source Life
a. Normal 4000 hrs, c. SmartEco 15000 hrs, b. ECO 10000 hrs
|
Light Source Life
a. Normal 5000 hrs, c. SmartEco 15000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
|
Light Source Life
a. Normal 20000 hrs, b. ECO 30000 hrs, c. SmartEco 20000 hrs
|
|
Optical | |||
Throw Ratio
1.13~1.47
|
Throw Ratio
1.49~1.64
|
Throw Ratio
1.15 ~ 1.5
|
|
Zoom Ratio
1.3x
|
Zoom Ratio
1.1x
|
Zoom Ratio
1.3x
|
|
Lens
F/# = 1.84 ~ 2.47, f = 12 ~ 15.6 mm
|
Lens
F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm
|
Lens
F/# = 2.59 ~ 2.87,
f = 16.88~21.88 mm
|
|
Projection Offset (Full-Height)
105%
|
Projection Offset (Full-Height)
108%
|
Projection Offset (Full-Height)
105.5%
|
|
Keystone Adjustment
1D, (Auto) Vertical ± 40 degrees
|
Keystone Adjustment
1D, Vertical ± 40 degrees
|
Keystone Adjustment
2D, (Auto) Vertical ± 40 degrees; Horizontal ± 40 degrees
|
|
Picture | |||
Rec. 709 Coverage
83%
|
Rec. 709 Coverage
|
Rec. 709 Coverage
92%
|
|
Picture Modes
Bright, Infographic, Presentation, Spreadsheet, Video Conference
|
Picture Modes
3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video
|
Picture Modes
3D, Bright, HDR10, HLG, Presentation, Spreadsheet, sRGB, User 1, User 2, Video Conference
|
|
Compatibility | |||
Input Lag
33.4 ms (1080P 60Hz)
|
Input Lag
33.4 ms (1080P 60Hz)
|
Input Lag
8.3 ms (1080P 120Hz)
|
|
Resolution Support
VGA(640 x 480) to Full HD(1920 x 1080)
|
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
Resolution Support
VGA (640 x 480) to 4K UHD (3840 x 2160)
|
|
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~135KHz
|
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
|
I/O Interface | |||
PC in (D-sub 15pin)
(x1)
|
PC in (D-sub 15pin)
PC in-1 (shared with component video)
|
PC in (D-sub 15pin)
|
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
|
|
HDMI in
(x2), HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4)
|
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
HDMI in
(x2), HDMI-1 (2.0b/HDCP2.2), HDMI-2 (2.0b/HDCP2.2)
|
|
LAN (RJ45)
(x1)
|
LAN (RJ45)
|
LAN (RJ45)
(x1)
|
|
USB Type A
USB Type A-1 (3.0/Power Supply1.5A), USB Type A-2 (3.0/Power Supply1.0A), USB Type A-3 (3.0/Power Supply1.0A), USB Type A-4 (2.0/Wireless Dongle), USB Type A-5 (2.0/Power Supply 0.9A)
|
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.0A/Reader), USB Type A-2 (2.0/Power Supply1.5A/Reader), USB Type A-3 (2.0/Wireless Dongle)
|
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.5A/Reader), USB Type A-2 (2.0/Power Supply 0.9A/Reader), USB Type A-3 (2.0/Power Supply 0.9A/Reader), USB Type A-4 (2.0/Wireless Dongle), USB Type A-5 (2.0/ Power Supply 0.9A/Service)
|
|
USB Type Mini B
(x1)
|
USB Type Mini B
(x1), USB Type Mini B-1(service/Page up&down)
|
USB Type Mini B
|
|
USB Type C
|
USB Type C
|
USB Type C
(x1), USB Type C-1 (2.0/DisplayPort Alt Mode/Reader)
|
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
|
Audio | |||
Speaker
(x2), 5W
|
Speaker
(x1), 2W
|
Speaker
(x1), 10W
|
|
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
|
|
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
|
Environment | |||
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
|
Typical Power Consumption (110V)
350W
|
Typical Power Consumption (110V)
270W/110V
|
Typical Power Consumption (110V)
200W @100VAC
|
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
|
Network Stand-by Power Consumption
|
Network Stand-by Power Consumption
|
Network Stand-by Power Consumption
<2W
|
|
Acoustic Noise (Typ./Eco.)(dB)
32/30
|
Acoustic Noise (Typ./Eco.)(dB)
33/29 dB
|
Acoustic Noise (Typ./Eco.)(dB)
34/28
|
|
Accessories | |||
Wireless USB dongle
(Standard), 5201BS
|
Wireless USB dongle
WDR02U
|
Wireless USB dongle
5201BS, (Standard)
|
|
Carry Bag
|
Carry Bag
(optional),5J.J3T09.001
|
Carry Bag
(Optional)
|
|
Remote Control w/ Battery
RCI023
|
Remote Control w/ Battery
RCI023
|
Remote Control w/ Battery
RCI024
|
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
|
VGA(D-sub 15pin) Cable
1 (1.5m)
|
VGA(D-sub 15pin) Cable
1 (1.5m)
|
VGA(D-sub 15pin) Cable
|
|
3D Glasses
(Optional), DGD5
|
3D Glasses
(Optional), DGD5
|
3D Glasses
|
|
Quick Start Guide
(x1) 21L
|
Quick Start Guide
(x1) 21L
|
Quick Start Guide
(x1) 21L
|
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
|
Universal Ceiling Mount
(Optional), CM00G3
|
Universal Ceiling Mount
(Optional), CM00G3
|
Universal Ceiling Mount
CM00G3, (Optional)
|
|
Onscreen Display | |||
Launcher
Uni Launcher
|
Launcher
Smart Business
|
Launcher
Smart Education
|
|
Smart System | |||
Built-in OS
Yes, Windows
|
Built-in OS
Yes, Android 6.0
|
Built-in OS
Yes, Android 9.0
|
|
Bluetooth
Yes, Bluetooth 4.2
|
Bluetooth
Yes, Bluetooth 4.0
|
Bluetooth
Yes, Bluetooth 4.0
|
|
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
|
Wireless Projection
AirPlay, Google Cast, Miracast
|
Wireless Projection
AirPlay, Google Cast
|
Wireless Projection
AirPlay, Google Cast, Miracast
|
|
Preload Apps
Skype for business, Teamviewer Meeting
|
Preload Apps
Teamviewer Meeting, Firefox
|
Preload Apps
|
|
Dimension & Weight | |||
Dimensions (WxHxD) (mm)
380 x 127 x 263
|
Dimensions (WxHxD) (mm)
296 x120 x232
|
Dimensions (WxHxD) (mm)
304 (W) x 112 (H) x 241 (D)
|
|
Net Weight (kg)
4.2
|
Net Weight (kg)
2.5 kg(5lbs)
|
Net Weight (kg)
3.0Kg +/- 100g
|
|
Dimensions (WxHXD) (inch)
14.9 x 4.9 x 10.35
|
Dimensions (WxHXD) (inch)
11.6 x4.7 x9.1
|
Dimensions (WxHXD) (inch)
11.9 (W) x 4.42 (H) x 9.49(D)
|
|
Net Weight (lb)
9.25
|
Net Weight (lb)
5
|
Net Weight (lb)
6.6 +/- 0.2lb
|
|
Projection System | |||
Projection System
DLP
|
Projection System
DLP
|
Projection System
DLP
|
Display | |||
---|---|---|---|
Brightness (ANSI lumens)
3600
|
|||
Resolution
WXGA (1280x800)
|
|||
Native Aspect Ratio
16:10
|
|||
Contrast Ratio (FOFO)
20,000:1
|
|||
Display Color
30-bit (1.07 billion colors)
|
|||
Light Source
Lamp
|
|||
Light Source Life
a. Normal 5000 hrs, c. SmartEco 15000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
|
|||
Optical | |||
Throw Ratio
1.55~1.7
|
|||
Zoom Ratio
1.1x
|
|||
Lens
F/#=2.56~2.68, f=22~24.1
|
|||
Projection Offset (Full-Height)
100%
|
|||
Keystone Adjustment
1D, Vertical ± 40 degrees
|
|||
Picture | |||
Picture Modes
3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video
|
|||
Compatibility | |||
Input Lag
33.4 ms (1080P 60Hz)
|
|||
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
|||
Horizontal Frequency
15K~102KHz
|
|||
Vertical Scan Rate
23~120Hz
|
|||
I/O Interface | |||
PC in (D-sub 15pin)
PC in-1 (shared with component video)
|
|||
Monitor out (D-sub 15pin)
(x1)
|
|||
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
|||
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.0A/Reader), USB Type A-2 (2.0/Power Supply1.5A/Reader), USB Type A-3 (2.0/Wireless Dongle)
|
|||
USB Type Mini B
(x1), USB Type Mini B-1(service/Page up&down)
|
|||
RS232 in (DB-9pin)
(x1)
|
|||
Audio | |||
Speaker
(x1), 2W
|
|||
Audio in (3.5mm Mini Jack)
(x1)
|
|||
Audio out (3.5mm Mini Jack)
(x1)
|
|||
Environment | |||
Operating Temperature
0~40℃
|
|||
Power Supply
AC 100 to 240 V, 50/60 Hz
|
|||
Typical Power Consumption (110V)
270W/110V
|
|||
Stand-by Power Consumption
<0.5W
|
|||
Acoustic Noise (Typ./Eco.)(dB)
33/29 dB
|
|||
Accessories | |||
Wireless USB dongle
WDR02U
|
|||
Carry Bag
(optional),5J.J3T09.001
|
|||
Remote Control w/ Battery
RCI023
|
|||
Power Cord (by region)
x1 (1.8M)
|
|||
VGA(D-sub 15pin) Cable
1 (1.5m)
|
|||
3D Glasses
(Optional), DGD5
|
|||
Quick Start Guide
(x1) 21L
|
|||
Warranty Card (by region)
Yes
|
|||
Universal Ceiling Mount
(Optional), CM00G3
|
|||
Onscreen Display | |||
Launcher
Smart Business
|
|||
Smart System | |||
Built-in OS
Yes, Android 6.0
|
|||
Bluetooth
Yes, Bluetooth 4.0
|
|||
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
|||
Wireless Projection
AirPlay, Google Cast
|
|||
Dimension & Weight | |||
Dimensions (WxHxD) (mm)
296 x120 x232
|
|||
Net Weight (kg)
2.5 kg(5lbs)
|
|||
Net Weight (lb)
5
|
|||
Projection System | |||
Projection System
DLP
|
Display | |||
---|---|---|---|
Brightness (ANSI lumens)
3600
|
Brightness (ANSI lumens)
4000
|
||
Resolution
XGA (1024x768)
|
Resolution
XGA (1024x768)
|
||
Native Aspect Ratio
4:3
|
Native Aspect Ratio
4:3
|
||
Contrast Ratio (FOFO)
20,000:1
|
Contrast Ratio (FOFO)
20,000:1
|
||
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
||
Light Source
Lamp
|
Light Source
Lamp
|
||
Light Source Life
a. Normal 5000 hrs, c. SmartEco 15000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
|
Light Source Life
a. Normal 6000 hrs, c. SmartEco 10000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
|
||
Optical | |||
Throw Ratio
1.96~2.15
|
Throw Ratio
1.96~2.15
|
||
Zoom Ratio
1.1x
|
Zoom Ratio
1.1x
|
||
Lens
F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm
|
Lens
F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm
|
||
Projection Offset (Full-Height)
110%
|
Projection Offset (Full-Height)
110%
|
||
Keystone Adjustment
1D, Vertical ± 40 degrees
|
Keystone Adjustment
1D, Vertical ± 40 degrees
|
||
Picture | |||
Picture Modes
3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video
|
Picture Modes
3D, Bright, Presentation, Spreadsheet, sRGB, User 1, User 2, Video Conference
|
||
Compatibility | |||
Input Lag
33.4 ms (1080P 60Hz)
|
Input Lag
33.4 ms (1080P 60Hz)
|
||
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
||
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~102KHz
|
||
Vertical Scan Rate
23~120Hz
|
Vertical Scan Rate
23~120Hz
|
||
I/O Interface | |||
PC in (D-sub 15pin)
PC in-1 (shared with component video)
|
PC in (D-sub 15pin)
PC in-1 (shared with component video)
|
||
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
||
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
||
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.0A/Reader), USB Type A-2 (2.0/Power Supply1.5A/Reader), USB Type A-3 (2.0/Wireless Dongle)
|
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.5A/Reader), USB Type A-2 (2.0/Power Supply 0.9A/Reader), USB Type A-3 (2.0/Power Supply 0.9A/Reader), USB Type A-4 (2.0/Wireless Dongle), USB Type A-5 (2.0/ Power Supply 0.9A)
|
||
USB Type Mini B
(x1), USB Type Mini B-1(service/Page up&down)
|
USB Type Mini B
(x1), USB Type Mini B-1(service)
|
||
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
||
Audio | |||
Speaker
(x1), 2W
|
Speaker
(x1), 5W
|
||
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1)
|
||
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
||
Environment | |||
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
||
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
||
Typical Power Consumption (110V)
270W/110V
|
Typical Power Consumption (110V)
275W@110V
|
||
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
||
Acoustic Noise (Typ./Eco.)(dB)
33/29 dB
|
Acoustic Noise (Typ./Eco.)(dB)
33/29 dB
|
||
Accessories | |||
Wireless USB dongle
WDR02U
|
Wireless USB dongle
5201BS, (Standard)
|
||
Carry Bag
(optional),5J.J3T09.001
|
Carry Bag
(Optional)
|
||
Remote Control w/ Battery
RCI023
|
Remote Control w/ Battery
RCI024
|
||
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (1.8M)
|
||
VGA(D-sub 15pin) Cable
1 (1.5m)
|
VGA(D-sub 15pin) Cable
|
||
3D Glasses
(Optional), DGD5
|
3D Glasses
|
||
Quick Start Guide
(x1) 21L
|
Quick Start Guide
(x1) 21L
|
||
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
||
Universal Ceiling Mount
(Optional), CM00G3
|
Universal Ceiling Mount
CM00G3, (Optional)
|
||
Onscreen Display | |||
Launcher
Smart Business
|
Launcher
Smart Education
|
||
Smart System | |||
Built-in OS
Yes, Android 6.0
|
Built-in OS
Yes, Android 9.0
|
||
Bluetooth
Yes, Bluetooth 4.0
|
Bluetooth
Yes, Bluetooth 4.0
|
||
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
||
Wireless Projection
AirPlay, Google Cast
|
Wireless Projection
AirPlay, Google Cast, Miracast
|
||
Dimension & Weight | |||
Dimensions (WxHxD) (mm)
296 x120 x232
|
Dimensions (WxHxD) (mm)
296(W) x120(H) x232(D)
|
||
Net Weight (kg)
2.5 kg(5lbs)
|
Net Weight (kg)
2.6 Kg +/- 200g
|
||
Net Weight (lb)
5
|
Net Weight (lb)
5.73 lbs + 0.44 lbs
|
||
Projection System | |||
Projection System
DLP
|
Projection System
DLP
|
Display | |||
---|---|---|---|
Brightness (ANSI lumens)
3800
|
|||
Resolution
WUXGA (1920x1200)
|
|||
Native Aspect Ratio
16:10
|
|||
Contrast Ratio (FOFO)
7,500:1
|
|||
Display Color
30-bit (1.07 billion colors)
|
|||
Light Source
Lamp
|
|||
Light Source Life
a. Normal 4000 hrs, c. SmartEco 8000 hrs, d. LampSave 15000 hrs, d. LampSave+ 20000 hrs, b. ECO 10000 hrs
|
|||
Optical | |||
Throw Ratio
0.9~1.08
|
|||
Zoom Ratio
1.2x
|
|||
Lens
NA
|
|||
Projection Offset (Full-Height)
100%
|
|||
Keystone Adjustment
2D, (Auto) Vertical ± 30 degrees; Horizontal ± 30 degrees
|
|||
Lens Shift Vertical
NA
|
|||
Lens Shift Horizontal
NA
|
|||
Picture | |||
Rec. 709 Coverage
83%
|
|||
Picture Modes
Bright, Presentation, Spreadsheet, User 1, User 2, Video Conference
|
|||
Compatibility | |||
Input Lag
33.4 ms (1080P 60Hz)
|
|||
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
|||
Horizontal Frequency
15K~102KHz
|
|||
I/O Interface | |||
PC in (D-sub 15pin)
(x1)
|
|||
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
|||
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.5A/Service), USB Type A-2 (2.0/Power Supply1.0A/Reader), USB Type A-3 (3.0/Power Supply1.0A), USB Type A-4 (2.0/Wireless Dongle), USB Type A-5 (2.0/Power Supply 0.9A)
|
|||
RS232 in (DB-9pin)
(x1)
|
|||
Audio | |||
Speaker
(x1), 5W
|
|||
Audio in (3.5mm Mini Jack)
(x1)
|
|||
Audio out (3.5mm Mini Jack)
(x1)
|
|||
Environment | |||
Operating Temperature
0~40℃
|
|||
Power Supply
AC 100 to 240 V, 50/60 Hz
|
|||
Typical Power Consumption (110V)
305W
|
|||
Stand-by Power Consumption
<0.5W
|
|||
Acoustic Noise (Typ./Eco.)(dB)
35 / 29
|
|||
Accessories | |||
Wireless USB dongle
(Standard), 5201BS
|
|||
Remote Control w/ Battery
RCI023
|
|||
Power Cord (by region)
x1 (1.8M)
|
|||
3D Glasses
(Optional), DGD5
|
|||
Installation Guide
Yes
|
|||
Warranty Card (by region)
Yes
|
|||
Universal Ceiling Mount
(Optional)
|
|||
Onscreen Display | |||
Launcher
Uni Launcher
|
|||
Smart System | |||
Built-in OS
Yes, Android 9.0
|
|||
Bluetooth
Yes, Bluetooth 4.2
|
|||
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
|||
Wireless Projection
AirPlay, Google Cast, Miracast
|
|||
Preload Apps
TeamViewer, BenQStore, Firefox, Youtube, Instashare2, AMS Servcie, X-Sign Broadcast, WPS, Dashboard
|
|||
Dimension & Weight | |||
Dimensions (WxHxD) (mm)
312*238.9*110.3
|
|||
Net Weight (kg)
2.9kg
|
|||
Net Weight (lb)
6.39lbs
|
|||
Projection System | |||
Projection System
DLP
|
Display | |||
---|---|---|---|
Brightness (ANSI lumens)
3300
|
Brightness (ANSI lumens)
3600
|
||
Resolution
WXGA (1280x800)
|
Resolution
WXGA (1280x800)
|
||
Native Aspect Ratio
16:10
|
Native Aspect Ratio
16:10
|
||
Contrast Ratio (FOFO)
20,000:1
|
Contrast Ratio (FOFO)
20,000:1
|
||
Display Color
30-bit (1.07 billion colors)
|
Display Color
30-bit (1.07 billion colors)
|
||
Light Source
Lamp
|
Light Source
Lamp
|
||
Light Source Life
a. Normal 5000 hrs, c. SmartEco 15000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
|
Light Source Life
a. Normal 6000 hrs, c. SmartEco 10000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
|
||
Optical | |||
Throw Ratio
0.49
|
Throw Ratio
0.49
|
||
Zoom Ratio
Fixed
|
Zoom Ratio
Fixed
|
||
Lens
F/# = 2.6,f = 6.9 mm
|
Lens
F/# = 2.6,f = 6.9 mm
|
||
Projection Offset (Full-Height)
105%
|
Projection Offset (Full-Height)
105%
|
||
Keystone Adjustment
1D, Vertical ± 30 degrees
|
Keystone Adjustment
1D, Vertical ± 40 degrees
|
||
Picture | |||
Picture Modes
3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video
|
Picture Modes
3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video Conference
|
||
Compatibility | |||
Input Lag
33.4 ms (1080p@60Hz)
|
Input Lag
33.4 ms (1080P 60Hz)
|
||
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
||
Horizontal Frequency
15K~102KHz
|
Horizontal Frequency
15K~102KHz
|
||
I/O Interface | |||
PC in (D-sub 15pin)
PC in-1 (shared with component video)
|
PC in (D-sub 15pin)
PC in-1 (shared with component video)
|
||
Monitor out (D-sub 15pin)
(x1)
|
Monitor out (D-sub 15pin)
(x1)
|
||
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
||
LAN (RJ45)
(x1)
|
LAN (RJ45)
(x1)
|
||
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.0A/Reader), USB Type A-2 (2.0/Power Supply1.5A/Reader), USB Type A-3 (2.0/Wireless Dongle)
|
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.5A/Reader), USB Type A-2 (2.0/Power Supply 0.9A/Reader), USB Type A-3 (2.0/Power Supply 0.9A/Reader), USB Type A-4 (2.0/Wireless Dongle), USB Type A-5 (2.0/ Power Supply 0.9A/PointWrite)
|
||
USB Type Mini B
(x1), USB Type Mini B-1(service/Page up&down)
|
USB Type Mini B
(x1), USB Type Mini B-1(PointWrite)
|
||
RS232 in (DB-9pin)
(x1)
|
RS232 in (DB-9pin)
(x1)
|
||
Audio | |||
Speaker
(x1), 2W
|
Speaker
(x1), 5W
|
||
Audio in (3.5mm Mini Jack)
(x1)
|
Audio in (3.5mm Mini Jack)
(x1)
|
||
Audio out (3.5mm Mini Jack)
(x1)
|
Audio out (3.5mm Mini Jack)
(x1)
|
||
Environment | |||
Operating Temperature
0~40℃
|
Operating Temperature
0~40℃
|
||
Power Supply
AC 100 to 240 V, 50/60 Hz
|
Power Supply
AC 100 to 240 V, 50/60 Hz
|
||
Typical Power Consumption (110V)
280
|
Typical Power Consumption (110V)
275W@110V
|
||
Stand-by Power Consumption
<0.5W
|
Stand-by Power Consumption
<0.5W
|
||
Network Stand-by Power Consumption
<2W
|
Network Stand-by Power Consumption
<2W
|
||
Acoustic Noise (Typ./Eco.)(dB)
33/29
|
Acoustic Noise (Typ./Eco.)(dB)
33/29
|
||
Accessories | |||
Wireless USB dongle
WDR02U
|
Wireless USB dongle
5201BS, (Standard)
|
||
Carry Bag
(optional),5J.J3T09.001
|
Carry Bag
(Optional)
|
||
Remote Control w/ Battery
RCI023
|
Remote Control w/ Battery
RCI024
|
||
Power Cord (by region)
x1 (1.8M)
|
Power Cord (by region)
x1 (3.0M)
|
||
VGA(D-sub 15pin) Cable
1 (1.8m)
|
VGA(D-sub 15pin) Cable
|
||
3D Glasses
(Optional), DGD5
|
3D Glasses
|
||
Quick Start Guide
(x1) 21L
|
Quick Start Guide
(x1) 21L
|
||
Warranty Card (by region)
Yes
|
Warranty Card (by region)
Yes
|
||
Anti-dust Filter
(Optional), All SKU
|
Anti-dust Filter
|
||
Universal Ceiling Mount
(Optional)
|
Universal Ceiling Mount
(Optional)
|
||
Wall Mount
(Optional), WM06G3
|
Wall Mount
(Optional), WM06G3
|
||
Onscreen Display | |||
Launcher
Smart Education
|
Launcher
Smart Education
|
||
Smart System | |||
Built-in OS
Yes, Android 6.0
|
Built-in OS
Yes, Android 9.0
|
||
Bluetooth
Yes, Bluetooth 4.0
|
Bluetooth
Yes, Bluetooth 4.0
|
||
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
||
Wireless Projection
AirPlay, Google Cast
|
Wireless Projection
AirPlay, Google Cast, Miracast
|
||
Dimension & Weight | |||
Dimensions (WxHxD) (mm)
296 x120 x250
|
Dimensions (WxHxD) (mm)
296(W) x120(H) x 250(D)
|
||
Net Weight (kg)
2.6
|
Net Weight (kg)
2.8kg +/- 200g
|
||
Projection System | |||
Projection System
DLP
|
Projection System
DLP
|
Display | |||
---|---|---|---|
Brightness (ANSI lumens)
3300
|
|||
Resolution
XGA (1024x768)
|
|||
Native Aspect Ratio
4:3
|
|||
Contrast Ratio (FOFO)
20,000:1
|
|||
Display Color
30-bit (1.07 billion colors)
|
|||
Light Source
Lamp
|
|||
Light Source Life
a. Normal 5000 hrs, c. SmartEco 15000 hrs, d. LampSave 15000 hrs, b. ECO 10000 hrs
|
|||
Optical | |||
Throw Ratio
0.61
|
|||
Zoom Ratio
Fixed
|
|||
Lens
F/# = 2.6,f = 6.9 mm
|
|||
Projection Offset (Full-Height)
115%
|
|||
Keystone Adjustment
1D, Vertical ± 30 degrees
|
|||
Picture | |||
Picture Modes
3D, Bright, Infographic, Presentation, sRGB, User 1, User 2, Video
|
|||
Compatibility | |||
Input Lag
33.4 ms (1080p@60Hz)
|
|||
Resolution Support
VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking
|
|||
Horizontal Frequency
15K~102KHz
|
|||
I/O Interface | |||
PC in (D-sub 15pin)
PC in-1 (shared with component video)
|
|||
Monitor out (D-sub 15pin)
(x1)
|
|||
HDMI in
(x1), HDMI-1 (1.4a/HDCP1.4)
|
|||
LAN (RJ45)
(x1)
|
|||
USB Type A
(x3), USB Type A-1 (2.0/Power Supply1.0A/Reader), USB Type A-2 (2.0/Power Supply1.5A/Reader), USB Type A-3 (2.0/Wireless Dongle)
|
|||
USB Type Mini B
(x1), USB Type Mini B-1(service/Page up&down)
|
|||
RS232 in (DB-9pin)
(x1)
|
|||
Audio | |||
Speaker
(x1), 2W
|
|||
Audio in (3.5mm Mini Jack)
(x1)
|
|||
Audio out (3.5mm Mini Jack)
(x1)
|
|||
Environment | |||
Operating Temperature
0~40℃
|
|||
Power Supply
AC 100 to 240 V, 50/60 Hz
|
|||
Typical Power Consumption (110V)
280
|
|||
Stand-by Power Consumption
<0.5W
|
|||
Network Stand-by Power Consumption
<2W
|
|||
Acoustic Noise (Typ./Eco.)(dB)
33/29
|
|||
Accessories | |||
Wireless USB dongle
WDR02U
|
|||
Carry Bag
(optional),5J.J3T09.001
|
|||
Remote Control w/ Battery
RCI023
|
|||
Power Cord (by region)
x1 (1.8M)
|
|||
VGA(D-sub 15pin) Cable
1 (1.8m)
|
|||
3D Glasses
(Optional), DGD5
|
|||
Quick Start Guide
(x1) 21L
|
|||
Warranty Card (by region)
Yes
|
|||
Anti-dust Filter
(Optional), All SKU
|
|||
Universal Ceiling Mount
(Optional)
|
|||
Wall Mount
(Optional), WM06G3
|
|||
Onscreen Display | |||
Launcher
Smart Education
|
|||
Smart System | |||
Built-in OS
Yes, Android 6.0
|
|||
Bluetooth
Yes, Bluetooth 4.0
|
|||
Wi-Fi Standard
802.11 a/b/g/n/ac (2.4G/5G)
|
|||
Wireless Projection
AirPlay, Google Cast
|
|||
Dimension & Weight | |||
Dimensions (WxHxD) (mm)
296 x120 x250
|
|||
Net Weight (kg)
2.6
|
|||
Projection System | |||
Projection System
DLP
|
